DYNAMICA MINI70I Marine Generator Inverter 6KW 50hz
MINI 70i
Yanmar L100N engine
Maximum power 6 kW
Continuous power 4.8 kW
Type: Diesel, 4-stroke, 1 cylinder
Power: 8.8 hp (6.5 kWm)
Bore/Stroke: 67.0 x 68.0 mm (2.64 x 2.68 inches)
Displacement: 435 cm3
Injection system: Indirect injection
Combustion: Naturally aspirated
Fuel system: In-line pump
Consumption at 100% load: 1.65 l/h
Starter battery: 12Vdc
Revolutions (rpm): 3300
Maximum inclination: 30°.
Water pump flow: 20 l/min
EE alternator
Type: Permanent magnets (PMG)
Insulation class: H
Automatic high-temperature shutdown: Yes
Cooling: Air/water (intercooler w/a)
Soundproof cab
Main structure: Aluminium
Panels: Aluminium
Paintwork: High resistance to atmospheric agents
Weight: 130 Kg
Noise level: 62 dB(A) at 7m
Height: 565 mm
Width: 468 mm
Length: 675 mm
- Phase
- Single phase
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230
- Engine
- Yanmar L100N
- Engine rpm (rpm)
- 3300
- Engine capacity (cm³)
- 435
- Cooling
- Heat exchanger air/water
- Inyección
- Indirect
- Alternator
- Permanent magnets
- Power (KW)
- 6
- Bore x stroke (mm)
- 67 x 68
- Lubrication
- Forced
- Motor insulation class
- H
- Acoustic pressure
- 62 dB(A) at 7 m
- Length (mm)
- 675
- Width (mm)
- 468
- Height (mm)
- 565
- Dry weight (Kg)
- 130
- Product type
- Generator
- Engine manufacturer
- Yanmar
- Brand
-
DYNAMICA MINI70I Marine Generator Inverter 6KW 50hz
DYNAMICA MINI70I: Power and Silence for Your Boating Needs
Looking for a compact, powerful and quiet inverter marine generator for your boat? The DYNAMICA MINI70I is the ideal solution.
Equipped with an 8.8 hp (6.5 kW) Yanmar L100N engine and a 6 kW inverter, the DYNAMICA MINI70I offers high performance and clean, reliable power generation.
Key features:
Yanmar L100N engine:
Diesel, 1 cylinder, 435 cm3
Electric start, 12V DC
Easy access for maintenance
Double anti-vibration system
Oil extraction pump
Alternator
Permanent magnet alternator (PMG)
Air/water cooling (intercooler)
Insulation class: H
Automatic high-temperature shutdown
Soundproof cabin:
Aluminium construction with weatherproof panels
Noise level of only 62 dB(A) at 7 metres
Control unit:
IP54 protection
Soft-touch buttons ON/OFF/START/STOP/MENU
Digital display for complete generator monitoring
Mod-Bus 485 connector for monitoring from the dashboard
GSM communication for start/stop and alarm reception
10-metre connection cable
If you are looking for a nautical generator like the MINI70E but with different technical features then you can browse the entire catalog of marine generators.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
