CGM 12.5DE - APERTO CON CENTRALINA AUTOMATICA

Reference CGM 15LW COFANATO AUTOMATICO /

OUT OF STOCK

Three-phase maximum power: 13.2 KW
Three-phase continuous use power: 12 KW
Three-phase maximum power: 16.5 KVA
Three-phase continuous use power: 15 KVA
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Current A: 22 A
Electrical protection: IP44
Motor: KOHLER KDW1603
Displacement cc: 1649
Engine revolutions: 1500 rpm
Bore x stroke: 75 x 77.6
Aspiration: Aspirated
Speed ??regulator: Mechanical
Number and arrangement of cylinders: 3 in line < br /> Cooling system: Water
Starting: Electric
Alternator: Linz, with brushes
Poles: 4
Voltage regulator system: Compound
Consumption: 3.3 Lt / h at 75% load
Tank capacity: 50 Lt
Autonomy: 15.1 h at 75% load
Acoustic pressure: 67 dB (A) at 7 meters
Length: 1600 mm
Width: 700 mm
Height: 1050 mm
Weight: 495 Kg

Download Technical data CGM 15LW

Product Details
Description

Phase: Single phase / Three phase
Maximum power three phase (KW): 13.2
Continuous power three phase (KW): 12
Maximum power three phase (KVA): 16.5
Continuous power three phase (KVA): 15
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230 / 400
Engine: KOHLER KDW1603
Engine rpm (rpm): 1500
Speed governor: Mechanical
Starting system: Electric
Engine capacity (cm³): 1649
Number cylinders: 3
Cylinders' position: In line
Cooling: Water
Alternator: With brushes
Poles: 4
Protection degree: IP44
Bore x stroke (mm): 75 x 77.6

Brand

^* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
