CGM 12.5DE - COFANATO CON CENTRALINA AUTOMATICA

CGM 25NG GAS METANO - APERTO CON CENTRALINA MANUALE
CGM 25NG GAS METANO - APERTO CON CENTRALINA MANUALE
CGM 12.5DE COFANATO AUTOMATICO /

DISCONTINUED

Download Technical data sheet CGM 12.5DE

Phase
Single phase
Height (mm)
840
Length (mm)
1200
Starting system
Electric
Width (mm)
690
Engine manufacturer
Kohler
Engine
KOHLER 25LD 425/2
Poles
2
Cooling
Air
Maximum power single phase (KW)
11
Continuous power single phase (KW)
10
Maximum power single phase (KVA)
13.75
Continuous power single phase (KVA)
12.5
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230
Engine rpm (rpm)
3000
Engine capacity (cm³)
851
Number cylinders
2
Oil capacity (L)
1.7
Alternator
Linz, brushless
Bore x stroke (mm)
75 x 77.6
Fuel tank capacity (L)
10
Consumption (L/h)
2.8 at 75% of the load
Running time (h)
3.6
Acoustic pressure
70 dB(A)
Dry weight (Kg)
235
Silenced
Yes
Super silenced
Yes
ATS Switch device
Optional ATS
Voltage regulator
Capacitor
Brand

* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
