GENSET MG 33 I-SY - SINGLE-PHASE/THREE-PHASE GENERATOR 30 KVA AVR
MG 33 I-SY
Maximum power Three-phase: 30 KVA
Maximum power Three-phase: 24 KW
Power continuous use Three-phase: 27 KVA
Power continuous use Three-phase: 21.6 KW
Maximum power Single-phase: 10 KVA
Maximum power Single-phase: 8 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98
Emissions Regulations: STAGE 0
Starting: Electric
Consumption: 6.4 Lt/h
Length: 1900 mm
Width: 910 mm
Height: 1100 mm
Weight: 690 Kg
Super silenced
AVR
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 8
- Maximum power single phase (KVA)
- 10
- Maximum power three phase (KW)
- 24
- Continuous power three phase (KW)
- Maximum power three phase (KVA)
- 30
- Continuous power three phase (KVA)
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 63A CEE - 1 x 400V 32A CEE - 1 x 230V 32A CEE - 1 x 230V 16A CEE
- Engine
- Yanmar 4TNV98, 4 stroke
- Emissions Regulations
- Stationary Use
- Engine rpm (rpm)
- 1500
- Starting system
- Elettrico
- Engine capacity (cm³)
- 3319
- Number cylinders
- 4
- Cooling
- Water
- Alternator
- Sincrono
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 40
- Consumption (L/h)
- 6.4
- Running time (h)
- 6.25
- Acoustic power
- 96 dB(A)
- Acoustic pressure
- 71 dB(A) at 7 m
- Length (mm)
- Width (mm)
- 910
- Height (mm)
- 1100
- Dry weight (Kg)
- 690
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Yanmar
- Brand
-
GENSET MG 33 I-SY
The GENSET MG 33 I-SY is a 30 KVA single/three phase diesel generator set with electric start and AVR voltage regulator.
Thanks to its compact size and its very low weight, the GENSET MG 33 I-SY is a light and easy to transport generator.
The GENSET MG 33 I-SY also has a low fuel consumption: only 6.4 Lt/h at 75% of the load.
The GENSET MG 33 I-SY generator set, thanks to the high quality and efficiency of its components, is ideal for various types of work: from small hobby jobs to large construction sites.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
