CGM 10DW - APERTO CON CENTRALINA MANUALE

CGM 25NG GAS METANO - APERTO CON CENTRALINA MANUALE
CGM 25NG GAS METANO - APERTO CON CENTRALINA MANUALE
CGM 25NG GAS METANO - APERTO CON CENTRALINA MANUALE
CGM 25NG GAS METANO - APERTO CON CENTRALINA MANUALE
CGM 10DW APERTO MANUALE /

Download Technical data sheet CGM 10DW

Phase
Single phase / Three phase
Protection degree
IP44
Height (mm)
850
Length (mm)
1400
Starting system
Electric
Width (mm)
700
Engine manufacturer
Lombardini
Engine
Lombardini LDW702
Poles
2
Sockets configuration
1 CEE 5P 400V 16A + 1 CEE 3P 230V 16A
Cooling
Water
Maximum power three phase (KW)
8.8
Continuous power three phase (KW)
8
Maximum power three phase (KVA)
11
Continuous power three phase (KVA)
10
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine rpm (rpm)
3000
Engine capacity (cm³)
686
Number cylinders
2
Cylinders' position
In line
Alternator
With brushes
Bore x stroke (mm)
75 x 77.6
Fuel tank capacity (L)
50
Consumption (L/h)
2.9 at 75% of the load
Running time (h)
17.2
Dry weight (Kg)
240
Silenced
No
Super silenced
No
ATS Switch device
No ATS
Voltage regulator
Compound
Brand

* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
