PRAMAC GBW10Y STAGE V APERTO CON QUADRO COMANDO AUTOMATICO
SH100TYAV02 /
OUT OF PRODUCTION
Maximum power Three-phase: 7.47 KW
Three-phase continuous use power: 6.81 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Yanmar 3TNV80F-NGPGE STAGE V
Starting: Electric
Consumption: 2.6 Lt/h at 100% of the load
Length: 1600 mm
Width: 870 mm
Height: 875 mm
Weight: 250 Kg
Compound
- Phase
- Three phase
- Maximum power three phase (KW)
- 7.47
- Continuous power three phase (KW)
- 6.81
- Maximum power three phase (KVA)
- 9.34
- Continuous power three phase (KVA)
- 8.51
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 32A 3P+N+T CEE
- Emissions Regulations
- Stage 5
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 1116
- Number cylinders
- 3
- Cylinders' position
- In line
- Oil capacity (L)
- 3.5
- Cooling
- Water
- Alternator
- Linz E1S13SB , with brushes
- Poles
- 4
- Fuel tank capacity (L)
- 51
- Consumption (L/h)
- 2 at 75% of the load / 2.6 at 100% of the load
- Running time (h)
- 25.6 at 75% of the load / 19.2 at 100% of the load
- Length (mm)
- 1600
- Width (mm)
- 870
- Height (mm)
- 875
- Dry weight (Kg)
- 250
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Yanmar
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
