PRAMAC E5000 THREE PHASE
PA542TH1000
Maximum power Single-phase: 3.04 KW
Power continuous use Single-phase: 2.8 KW
Maximum power Three-phase: 5 KW
Power continuous use Three-phase: 4.3 KW
Fuel: Gasoline
Voltage: 230 V / 400 V
Frequency: 50 Hz
Engine: Honda GX270 Recoil
Starting: Tear-off
Consumption: 2.2 Lt/h at 100% of load
Length: 715 mm
Width: 540 mm
Height: 490 mm
Weight: 70 Kg
Compound
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 3.04
- Continuous power single phase (KW)
- 2.8
- Maximum power single phase (KVA)
- 3.8
- Continuous power single phase (KVA)
- 3.5
- Maximum power three phase (KW)
- 5
- Continuous power three phase (KW)
- 4.3
- Maximum power three phase (KVA)
- Continuous power three phase (KVA)
- 5.4
- Fuel
- Gasoline
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 16A 3P+N+T CEE IP44 - 1 x 230V 16A SCHUKO IP54 - 1 x 230V 16A 2P+T CEE IP44
- Engine
- Honda GX270 Recoil, naturally aspirated
- Engine rpm (rpm)
- 3000
- Speed governor
- Mechanical
- Ignition
- Recoil
- Starting system
- Pull starter
- Engine capacity (cm³)
- 270
- Oil capacity (L)
- 1.1
- Cooling
- Air
- Alternator
- With brushes
- Poles
- 2
- Fuel tank capacity (L)
- 5.3
- Consumption (L/h)
- 1.6 at 75% of the load / 2.2 at 100% of the load
- Running time (h)
- 3.2 at 75% of the load / 2.4 at 100% of the load
- Acoustic power
- 97 dB(A)
- Acoustic pressure
- 69 dB(A) at 7 m
- Length (mm)
- 715
- Width (mm)
- 540
- Height (mm)
- 490
- Dry weight (Kg)
- 70
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- No ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Honda
- Brand
-
Motore benzina Honda GX. Raffreddamento ad aria. Protezione Oil Guard. Avviamento a strappo. Alternatore sincrono. Robusta struttura con telaio tubolare portante. Prese su cuffia con protezioni termiche
L'immagine è puramente indicativa
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
