TECNOGEN PK72TSS Generator set

TECNOGEN H2700
TECNOGEN H2700
PK72TSS

Maximum three-phase power: 57.6 kW or 72 kVA
Power supply: diesel
Voltage: 400 V
Motor: Perkins 1104A-44TG1
Starting: electric
Length: 2450 mm
Width: 1050 mm
Height: 1450 mm
Weight: 1150 kg

Download Scheda tecnica PK72TSS

Phase
Three phase
Height (mm)
1450
Length (mm)
2450
Starting system
Electric
Width (mm)
1050
Engine manufacturer
Perkins
Engine
HONDA GC160
Cooling
Water
Maximum power three phase (KW)
57.6
Maximum power three phase (KVA)
72
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
400
Engine rpm (rpm)
1500
Speed governor
Mechanical
Engine capacity (cm³)
4400
Number cylinders
4
Fuel tank capacity (L)
109
Consumption (L/h)
10
Running time (h)
10.9
Acoustic pressure
67 dB(A) at 7 m
Dry weight (Kg)
1150
Silenced
No
Super silenced
Yes
ATS Switch device
Optional ATS
Voltage regulator
No
Brand

TECNOGEN PK72TSS Generator Set.

TECNOGEN PK72TSS Generator set is a three-phase diesel generator set with a maximum output of 57.6 kW or 72 kVA. It is powered by a Perkins 1104A-44TG1 engine and has an output voltage of 400 V.

The main features of the TECNOGEN PK72TSS Generator Set are:

Maximum three-phase power: 57.6 kW or 72 kVA
Power supply: diesel
Voltage: 400 V
Motor: Perkins 1104A-44TG1
Starting: electric
Length: 2450 mm
Width: 1050 mm
Height: 1450 mm
Weight: 1150 kg

TECNOGEN Electric Unit PK72TSS is suitable for a wide range of applications, including:

Emergency power supply in case of power outages

Powering industrial machinery

Powering civil buildings

The TECNOGEN PK72TSS Generator set is available in two versions: open on base or super-silenced. The open-on-base version is cheaper and easier to install, while the super-silenced version is more expensive but offers better sound insulation.

Specifically, the super-silenced version of the TECNOGEN PK72TSS Generator set has a sound pressure level of 67 dB(A) at a distance of 7 meters. This level is below the 70 dB(A) limit imposed by Italian regulations for gensets installed in residential areas.

TECNOGEN PK72TSS Generator set is the ideal solution for those looking for a reliable, versatile and quiet genset. It is perfect for providing emergency power during outages, but can also be used to industrial machinery or civil buildings.

TECNOGEN PK72TSS Generator set can provide  for a wide range of equipment, from domestic to industrial. For example, it can be used to power a medium-sized home, a small office, or a workshop.

TECNOGEN PK72TSS Generator set is the ideal solution for those looking for a reliable, versatile and quiet genset.

If you are looking for a similar product or one with similar features click HERE.

The picture is purely indicative.

TECNOGEN PK72TSS

* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
