PRAMAC S12000 THREE-PHASE Generator set +DPP, AVR
PD123TH200H
Potenza Consumo uso continuativo: 10 kva
Tipo carburante: Benzina
Capacità serbatoio carburante: 24 LT
Autonomia: 6.1 h al 75% del carico
Dimensioni: L 96 cm x L 64.1 cm x A 66.7 cm
Peso a secco: 162 Kg
Potenza acustica LpA: 96 LWA dB(A)
Configurazione delle prese: 1 x Schuko ,1 x 230V 16A ,1 x 230V 32A
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 4.48
- Continuous power single phase (KW)
- 4
- Maximum power single phase (KVA)
- 5.6
- Continuous power single phase (KVA)
- 5
- Maximum power three phase (KW)
- 11.1
- Continuous power three phase (KW)
- 9.5
- Maximum power three phase (KVA)
- 13.9
- Continuous power three phase (KVA)
- 11.8
- Fuel
- Gasoline
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- Engine
- Honda GX160, naturally aspirated
- Engine rpm (rpm)
- 3000
- Speed governor
- Mechanical
- Starting system
- Elettrico
- Engine capacity (cm³)
- Oil capacity (L)
- 1.9
- Cooling
- Air
- Poles
- 2
- Fuel tank capacity (L)
- 24
- Consumption (L/h)
- 4.23 at 75% of the load / 5.63 at 100% of the load
- Running time (h)
- 5.67 at 75% of the load / 4.26 at 100% of the load
- Acoustic power
- 96 dB(A)
- Acoustic pressure
- 72 dB(A) at 7 m
- Length (mm)
- 960
- Width (mm)
- 641
- Height (mm)
- 667
- Dry weight (Kg)
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Honda
- Brand
-
PRAMAC S12000 THREE PHASE DPP AVR.
Introducing the PRAMAC S12000, a state-of-the-art three-phase generator with DPP AVR technology. Designed to deliver consistent and reliable power, this model ensures optimal voltage stability across all operations. The PRAMAC S12000 epitomizes high-end performance coupled with precision engineering, making it an indispensable asset for diverse power needs.
Motor Honda Serie GX.
The image is purely indicative
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
