PRAMAC GSW10Y COFANATO CON QUADRO COMANDO MANUALE (MCP)


Phase
Three phase
Height (mm)
1965
Length (mm)
2650
Starting system
Electric
Width (mm)
1180
Engine manufacturer
Volvo
Engine
VOLVO TAD733GE, turbo intercooled
Poles
4
Cooling
Water
Maximum power three phase (KW)
176
Continuous power three phase (KW)
162.14
Maximum power three phase (KVA)
220
Continuous power three phase (KVA)
202.67
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
400
Emissions Regulations
Stage 2
Speed governor
Electronic
Engine capacity (cm³)
7150
Number cylinders
6
Cylinders' position
In line
Oil capacity (L)
34
Alternator
Mecc Alte ECO38-2SN/4, brushless
Fuel tank capacity (L)
400
Consumption (L/h)
34.9 at 75% of the load / 46.5 at 100% of the load
Running time (h)
11.5 at 75% of the load / 8.6 at 100% of the load
Dry weight (Kg)
2026
Silenced
No
Super silenced
No
ATS Switch device
No ATS
Voltage regulator
AVR
Brand

* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
