PRAMAC GBW15Y APERTO CON QUADRO COMANDO AUTOMATICO
SH130TYAK02 /
OUT OF PRODUCTION
Potenza Consumo uso continuativo: 13 kva
Tipo carburante: Diesel
Capacità serbatoio carburante: 51 LT
Autonomia: 18 h al 75% del carico
Dimensioni: L 160 cm x L 87 cm x A 95 cm
Peso a secco: 390 Kg
- Phase
- Three phase
- Maximum power three phase (KW)
- 11.44
- Continuous power three phase (KW)
- 10.4
- Maximum power three phase (KVA)
- 14.3
- Continuous power three phase (KVA)
- 13
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 32A 3P+N+T CEE
- Engine
- Yanmar 3TNV88-BGPGE, naturally aspirated
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 1642
- Number cylinders
- 3
- Cylinders' position
- In line
- Oil capacity (L)
- 6.9
- Cooling
- Water
- Alternator
- Linz E1S13MD, with brushes
- Poles
- 4
- Fuel tank capacity (L)
- 51
- Consumption (L/h)
- 2.8 at 75% of the load / 3.8 at 100% of the load
- Running time (h)
- 18 at 75% of the load / 13.5 at 100% of the load
- Length (mm)
- 1600
- Width (mm)
- 870
- Height (mm)
- 950
- Dry weight (Kg)
- 390
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Yanmar
- Brand
-
Motore Diesel. Raffreddamento ad acqua. Silenziatore industriale. Base forcabile con carrelli. Liquidi motore e batteria carica. Quadro manuale MCP fornito di serie con 5 prese
L'immagine è puramente indicativa
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
