GENSET MG 66 S-I - SINGLE-PHASE/THREE-PHASE GENERATOR 66 KVA AVR
MG 66 S-I
OUT OF PRODUCTION
Maximum power Three-phase: 66 KVA
Maximum power Three-phase: 52.8 KW
Power continuous use Three-phase: 60 KVA
Power continuous use Three-phase: 48 KW
Maximum power Single-phase: 22 KVA
Maximum power Single-phase: 17.6 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Motor: FPT NEF 45 SM1A
Starting: Electric
Consumption: 10.2 Lt/h
Length: 2900 mm
Width: 1100 mm
Height: 1800 mm
Weight: 1400 Kg
Super silenced
AVR
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 17.6
- Maximum power single phase (KVA)
- 22
- Maximum power three phase (KW)
- 60
- Continuous power three phase (KW)
- 48
- Maximum power three phase (KVA)
- 66
- Continuous power three phase (KVA)
- 52.8
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- Terminal box
- Engine
- FPT (IVECO) NEF45SM1A turbo
- Emissions Regulations
- Stationary Use
- Engine rpm (rpm)
- 1500
- Starting system
- Electric
- Engine capacity (cm³)
- 4500
- Number cylinders
- 4
- Cooling
- Water
- Alternator
- Synchronous
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 230
- Consumption (L/h)
- 8.1
- Running time (h)
- 22.5
- Acoustic power
- 95 dB(A)
- Acoustic pressure
- 70 dB(A) at 7 m
- Length (mm)
- 2900
- Width (mm)
- 1100
- Height (mm)
- 1800
- Dry weight (Kg)
- 1400
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- ATS Included
- Voltage regulator
- AVR
- Engine manufacturer
- FPT Iveco
- Brand
-
GENSET MG 66 S-I
The GENSET MG 66 S-I is a 66 KVA single/three phase diesel generator set with electric start and AVR voltage regulator.
The GENSET MG 66 S-I also has a low fuel consumption: only 10.2 Lt/h at 75% of the load.
Thanks to the high quality and efficiency of its components, the GENSET MG 66 S-I generator set is ideal for various types of professional work such as on large construction sites.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
