Data sheet

Phase

Three phase

Maximum power three phase (KW)

88

Continuous power three phase (KW)

80

Maximum power three phase (KVA)

110

Continuous power three phase (KVA)

100

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

Deutz BF4M1013EC, turbo intercooler

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

4764

Number cylinders

4

Cylinders' position

In line

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Protection degree

IP44

Bore x stroke (mm)

108 x 130

Fuel tank capacity (L)

120

Consumption (L/h)

16.5

Running time (h)

7.3

Acoustic pressure

69 dB(A) at 7 m

Length (mm)

2500

Width (mm)

1050

Height (mm)

1550

Dry weight (Kg)

1450

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Deutz
