PLASMA CUTTERS

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2500/3000 VA Type of cut: Plasma cutter Open-circuit voltage: 310 V Current regulation: 10 - 25 A / 10 - 30 A Duty cycle at 40°: 25 A at 40% - 12 A at 100% / 30 A at 30% - 12 A at 100% Maximum current: 25 A / 30 A Separation cut: 8 mm / 10 mm Air pressure: 4.5 bar Air...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3300 VA Type of cut: Plasma cutter Open-circuit voltage: 350 V Current regulation: 10 - 40 A Duty cycle at 40°: 20 A at 40% - 25 A at 60% - 20 A at 100% Maximum current: 40 A Separation cut: 15 mm Quality cut 25 cm/min: 13 mm Air pressure: 4 - 5.5 bar Air capacity:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2800 VA Type of cut: Plasma cutter Open-circuit voltage: 310 V Current regulation: 10 - 30 A Duty cycle at 40°: 30 A at 30% - 12 A at 100% Maximum current: 30 A Separation cut: 10 mm Air pressure: 4 - 5 bar Air capacity: 100 Lt/min Insulation: H Degree of...

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 115/230 V Power: 2300 VA (115 V) / 3300 VA (230 V) Type of cut: Plasma cutter Open-circuit voltage: 480 V Current regulation: 20 - 30 A (115 V) / 20 - 40 A (230 V) Duty cycle at 40°: 30 A at 35% - 20 A at 100% (115 V) / 40 A at 40% - 25 A at 100% (230 V) Maximum current:...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5 KVA Type of cut: Plasma cutter Open-circuit voltage: 270 V Current regulation: 20 - 45 A Duty cycle at 40°: 45 A al 50% - 32 A al 100% Maximum current: 45 A Separation cut: 22 mm Quality cut 25 cm/min: 15 mm Air pressure: 5 bar Air capacity: 220 Lt/min<br...
