HELVI

Product type: Spot welding gun Length: 2 m Connector: 50 mm² 3 Pin Available for: SPOT CAR 4000

OUT OF PRODUCTION Phase type: Single-phase Frequency: 50/60 Hz Voltage: 115 V / 230 V Power: 2700 W (115 V) / 2900 W (230 V) Type of welding: MMA / TIG Open-circuit voltage: 55 V Current regulation: 10 - 100 A (115 V) / 10 - 200 A (230 V) Duty cycle at 40°: 100 A at 30% - 80 A at 60% (115 V) / 200 A at 25% - 130 A at 60% (230 V) Max. current:...

Product type: Spot welding gun Length: 2 m Connector: 70 mm² 3 Pin Available for: SPOT CAR 5000

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5300 W (MMA) / 4200 W (TIG) Type of welding: MMA / TIG Open-circuit voltage: 64 V Current regulation: 10 - 170 A (MMA) / 10 - 200 A (TIG) Duty cycle at 40°: 170 A at 25% - 110 A at 60% - 85 A at 100% (MMA) / 200 A at 25% - 130 A at 60% - 100 A at 100% (TIG) Maximum current: 170 A (MMA)...

Product type: Ground cable for spot welding Connector: 50 mm² Available for: SPOT CAR 4000

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2400 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 28 V Current regulation: 30 - 145 A Duty cycle at 40°: 130 A at 20% - 75 A at 60% Maximum current: 145 A Adjustment positions: 4 Steel welding wire diameter: 0.6 - 0.8 mm Stainless steel welding wire diameter:...

Product type: Ground cable for spot welding Connector: 70 mm² Available for: SPOT CAR 5000

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3000 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 37 V Current regulation: 30 - 170 A Duty cycle at 40°: 165 A at 15% - 83 A at 60% Maximum current: 170 A Adjustment positions: 6 Steel welding wire diameter: 0.6 - 0.8 mm Stainless steel welding wire diameter:...

Product type: Ground cable for MMA/TIG welding 10 mm² cable Length: 1.6 m Connector: 25 mm² Current: 140 Amp Available for: SPARC 146

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 3000 W Type of welding: MIG / MAG Open-circuit voltage: 23 - 42 V Current regulation: 30 - 180 A Duty cycle at 40°: 180 A at 15% - 93 A at 60% Maximum current: 180 A Adjustment positions: 6 Steel welding wire diameter: 0.6 - 0.8 mm Stainless steel welding wire diameter:...

PRODUCT OUT OF PRODUCTION AND HAS BEEN REPLACED BY: HELVI GALILEO 200 Phase type: Single phase Frequency: 50/60 Hz Voltage: 230 V Power: 6000 W Welding type: MMA / TIG No-load voltage: 48 V Current regulation: 5 -...

Product type: Ground cable for MMA/TIG welding 10 mm² cable Length: 2 m Connector: 25 mm² Current: 140 Amp Available for: SPARC 146

Product type: Ground cable for MMA/TIG welding 16 mm² cable Length: 2 m Connector: 25 mm² Current: 180 Amp Available for: FOX 185 / FOX 189 / EASYMIG 208 / SPARC 146 / SPARC 186 / SPARC 226 / TP 195

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 4600 W Type of welding: MIG / MAG No-load voltage: 19 - 34 V Current regulation: 30 - 220 A Duty cycle at 40°: 200 A at 20% - 125 A at 60% Maximum current: 220 A Adjustment positions: 8 Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding wire diameter: 0.8 - 1...

Product type: Ground cable for MMA/TIG welding 16 mm² cable Length: 2 m Connector: 50 mm² Current: 180 Amp Available for: FLEXY 160

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5500 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 43 V Current regulation: 30 - 250 A Duty cycle at 40°: 200 A at 35% - 145 A at 60% Maximum current: 250 A Adjustment positions: 8 Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding wire diameter:...

Product type: Ground cable for MMA/TIG welding 25 mm² cable Length: 2 m Connector: 50 mm² Current: 300 Amp Available for: GALILEO 179 / GALILEO 219 / GALILEO 219 HF / FLEXY 200 / FOX 211

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 7400 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 46 V Current regulation: 30 - 280 A Duty cycle at 40°: 250 A at 30% - 180 A at 60% Maximum current: 280 A Adjustment positions: 8 Steel welding wire diameter: 0.6 - 1.2 mm Stainless steel welding wire diameter:...

Product type: Ground cable for MMA/TIG welding 25 mm² cable Length: 3 m Connector: 25 mm² Current: 300 Amp Available for: MONOMIG 216 / MONOMIG 246 / MONOMIG 286 / EASYMIG 238 / MAXIMIG 278

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 3500 W Type of welding: MIG / MAG Open-circuit voltage: 16.5 - 32 V Current regulation: 30 - 190 A Duty cycle at 40°: 190 A at 25% - 130 A at 60% Maximum current: 190 A Adjustment positions: 7 Steel welding wire diameter: 0.6 - 1 mm Stainless steel...

Product type: Ground cable for MMA/TIG welding 35 mm² cable Length: 3 m Connector: 50 mm² Current: 400 Amp Available for: MAXIMIG 298 / UNIMIG 298

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 5900 W Type of welding: MIG / MAG Open-circuit voltage: 17 - 38 V Current regulation: 30 - 240 A Duty cycle at 40°: 230 A at 35% - 175 A at 60% Maximum current: 240 A Adjustment positions: 7 Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding...

Product type: MMA/TIG Welding cable 10 mm² cable Length: 2.4 m Connector: 25 mm² Current: 140 Amp Available for: SPARC 146

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 6400 W Type of welding: MIG / MAG Open-circuit voltage: 17 - 43 V Current regulation: 30 - 250 A Duty cycle at 40°: 250 A at 30% - 185 A at 60% Maximum current: 250 A Adjustment positions: 10 Steel welding wire diameter: 0.6 - 1 mm Stainless steel...

Product type: MMA/TIG Welding cable 16 mm² cable Length: 3 m Connector: 25 mm² Current: 180 Amp Available for: SPARC 186 / SPARC 226 / TP 195 / FOX 185

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 6400 W Type of welding: MIG / MAG Open-circuit voltage: 17 - 43 V Current regulation: 30 - 250 A Duty cycle at 40°: 250 A at 30% - 185 A at 60% Maximum current: 250 A Adjustment positions: 10 Steel welding wire diameter: 0.6 - 1 mm Stainless steel...

Product type: MMA/TIG Welding cable 16 mm² cable Length: 3 m Connector: 50 mm² Current: 180 Amp Available for: FLEXY 160 / FOX 211

Phase type: Single-phase / Three-phase Frequency: 50/60 Hz Voltage: 230/400 V Power: 9500 W Type of welding: MIG / MAG Open-circuit voltage: 18 - 45 V Current regulation: 30 - 300 A Duty cycle at 40°: 300 A at 35% - 230 A at 60% - 180 A at 100% Maximum current: 300 A Adjustment positions: 14 Steel welding wire diameter: 0.6 - 1.2 mm<br...

Product type: MMA/TIG Welding cable 25 mm² cable Length: 3 m Connector: 50 mm² Current: 250 Amp Available for: GALILEO 179 / GALILEO 219 / GALILEO 219HF / FLEXY 200 / FOX 211

Product type: Coil of copper-plated steel wire Coil diameter: 300 mm Wire diameter: 0.6 mm Weight: 15 kg Available for MIG/MAG welding machines

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1900 VA Type of welding: Multiprocess Open-circuit voltage: 54 V (MMA) / 24 V (MIG) Current regulation: 20 - 150 A (MMA) / 25 - 150 A (MIG) Duty cycle at 40°: 100 A at 40% - 65 A at 100% (MMA) / 150 A at 25% - 75 A at 100% (MIG) Maximum current: 150 A Steel welding wire diameter:...

Product type: Coil of copper-plated steel wire Coil diameter: 300 mm Wire diameter: 0.8 mm Weight: 15 kg Available for MIG/MAG welding machines

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1900 VA Type of welding: Multiprocess Open-circuit voltage: 54 V (MMA) / 24 V (MIG) Current regulation: 20 - 180 A (MMA) / 25 - 180 A (MIG) Duty cycle at 40°: 180 A at 20% - 75 A at 100% Maximum current: 180 A Steel welding wire diameter: 0.6 - 1 mm Stainless steel welding...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 1900 VA Type of welding: Multiprocess Open-circuit voltage: 54 V (MMA) / 24 V (MIG) Current regulation: 20 - 150 A (MMA) / 25 - 150 A (MIG) Duty cycle at 40°: 100 A at 40% - 65 A at 100% (MMA) / 150 A at 25% - 75 A at 100% (MMA) Maximum current: 150 A Steel welding wire diameter:...

Product type: Coil of copper-plated steel wire Coil diameter: 300 mm Wire diameter: 1  mm Weight: 15 kg Available for MIG/MAG welding machines

Product type: Coil of copper-plated steel wire Coil diameter: 300 mm Wire diameter: 1.2 mm Weight: 15 kg Available for MIG/MAG welding machines

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 5500 VA Type of welding: Multiprocess Open-circuit voltage: 65 V (MMA) / 65 V (TIG) / 35 V (MIG) Current regulation: 5 - 200 A (MMA) / 5 - 200 A (TIG) / 20 - 200 A (MIG) Duty cycle at 40°: 200 A at 35% - 120 A at 100% (MMA) / 200 A at 35% - 120 A at 100% (TIG) / 200 A at 35% - 140 A at 100%...

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 115 V / 230 V Power: 2700 W (115 V) / 2900 W (230 V) Type of welding: MMA / TIG Open-circuit voltage: 55 V Current regulation: 10 - 100 A (115 V) / 10 - 160 A (230 V) Duty cycle at 40°: 100 A at 30% - 80 A at 60% (115 V) / 160 A at 25% - 105 A at 60% (230 V) Maximum current: 100 A (115 V) / 160 A...

Product type: Coil of stainless steel wire Coil diameter: 300 mm Wire diameter: 0.8 mm Weight: 15 kg Available for MIG/MAG welding machines

Phase type: Single-phase Frequency: 50/60 Hz Voltage: 230 V Power: 2800 VA Type of welding: Multiprocess Open-circuit voltage: 55 V (MMA) / 55 V (TIG) / 27 V (MIG) Current regulation: 5 - 160 A (MMA) / 5 - 170 A (TIG) / 25 - 170 A (MIG) Duty cycle at 40°: 170 A at 25% - 110 A at 60% - 85 A at 100% (MMA) / 170 A at 25% - 110 A at 60% - 85 A at 100% (TIG) /...
