TELAIR TSP 130W
19735
Rated power (Pmax): 130W
Rated voltage Pmax (Vmp): 18.36V
Rated current Pmax (Imp): 7.10A
Open circuit voltage (Voc): 22.03V
Short-circuit current (Isc): 7.80A
Maximum system voltage: 1000VDC (IEC)
Class of application: Class A
Maximum overcurrent: 15 A
Operating temperature: 85% Rh -40°C~ +85°C
Nominal cell operating temperature (NOCT): 47 ± 2°C
Front cover: 3.2 mm tempered glass
Monocrystalline cells (pcs and dimensions): 36 - 156x156mm
Frame: anodized aluminum alloy
Junction box (degree of protection): IP65
Cable (length/section): 650 mm/4 mm2
Connector (degree of protection): IP65
Module dimensions (WxHxD) (without feet): 1160x830x35 mm
STC| radiation 1000W/m2, cell temperature 25°C, air mass AM 1.5 according to EN60904-3
Average efficiency reduction: 4.5% at 200W/m2 according to EN60904-1
Weight: 11.6 Kg
- Nominal voltage Umpp STC 25°C (V)
- 18.36
- Nominal current Impp STC 25°C (A)
- 7.10
- Net power (kW)
- 0.13
- Length (mm)
- 1160
- Width (mm)
- 550
- Height (mm)
- 35
- Cell composition
- Monocristalline 156x156 mm
- Weight (Kg)
- 11.7
- Brand
-
Solar panel 130W, with 6 mt cable, accessories kit (4 feet inABS+spoiler, aluminium cable gland, 10A/12V battery charger regulator for 1 battery, and cleaning and fixing kit(TEROSON MS930)
The image is purely indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
