FISCHER PANDA PVMV-N 10000x 8 kW Vehicole Generator
0013313
Frequency [Hz] 50
Generator manufacturer Fischer Panda GmbH
Isolation class of windings H
Nominal Speed [rpm] 3000 rpm
Voltage Regulation xControl
Voltage Tolerance ±3%
Power rating factor Cos Pi 0.85
Engine Speed [rpm] 3000
Nominal Voltage in Volt 230
Nominal Performance in kW)1) 8
Nominal Performance in kVA1) 9.4
Continuous Performance in kW1) 7.2
Continuous Performance in kVA1) 8.5
Number of Phases 1
Frequency [Hz] 50
Engine Manufacturer Kubota (KU)
Engine Type Z602
No. Cylinders 2
Displacement [cm3] 599
Starter System 12V (24V Optional)
Sound Cover Type GFK (Glass fibre reinforced polyester)
Sound Insulation Material 4DS
Lenght: 760 mm
Width: 580 mm
Height: 609 mm
Weight: 195 Kg
- Phase
- Single phase
- Maximum power single phase (KW)
- 8
- Continuous power single phase (KW)
- 7.2
- Maximum power single phase (KVA)
- 9.4
- Continuous power single phase (KVA)
- 8.5
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230
- Engine rpm (rpm)
- 3000
- Starting system
- Electric 12 Vcc
- Engine capacity (cm³)
- 599
- Number cylinders
- 2
- Cooling
- Water
- Motor insulation class
- H
- Acoustic pressure
- 52 dB(A) at 7 m
- Length (mm)
- 760
- Width (mm)
- 580
- Height (mm)
- 609
- Dry weight (Kg)
- 195
- Silenced
- Yes
- Super silenced
- Yes
- Voltage regulator
- Capacitor
- Engine manufacturer
- Kubota
- Brand
-
Fixed speed generators. Perfect for installation within the vehicle and the ideal choice in all cases where space and length is available.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
