PRAMAC TG25/3 IP23 Cardan generator Single/Three-Phase 25 kVA

PRAMAC TG25/3 IP23 Cardan generator, 12 kVA single-phase and 25 kVA three-phase, with tractor connection at 3000 rpm. The PRAMAC TG25/3 IP23 Cardan generator has a voltage of 230 V / 400 V and a frequency of 50 Hz. The alternator of the PRAMAC TG25/3 IP23 PTO generator features a compound voltage regulator. The compound regulator stabilizes the voltage and prevents damage to connected devices. The TG25/3 IP23 Cardan generator is highly reliable as it has been built and designed using high-quality materials.
Easy to transport, install, and position thanks to its compact size, this model is ideal for mounting on a tractor unit. The PRAMAC TG25/3 IP23 Cardan generator requires a tractor power of 44 kW / 60 HP and a PTO speed of 435 rpm.

Technical specifications of the PRAMAC TG25/3 IP23 Cardan generator Single-Three-Phase:
Continuous power single-phase: 12 kW
Continuous power three-phase: 20 kW
Voltage: 230 V / 400 V
Frequency: 50 Hz
Generator speed: 435 rpm
Required tractor power: 44 kW / 60 HP
Length: 958 mm
Width: 645 mm
Height: 1003 mm
Weight: 154 kg
Compound

Outlets:
N.1 SCHUKO 230V 16A IP54
N.1 2P+T CEE 230V 32A IP44
N.1 3P+N+T CEE 400V 32A IP44

The PRAMAC TG25/3 IP23 Cardan generator is a professional tractor-driven unit developed by Pramac, making it one of the best choices compared to its competitors. The PRAMAC TG25/3 IP23 Cardan generator features a robust structure with a protective tubular frame. This series is the ideal solution for agricultural applications, enabling access to remote areas even under adverse weather conditions.
The TG25/3 IP23 Cardan generator is equipped with thermal-magnetic protection, residual current protection, voltmeter, and frequency meter.

If you are looking for a Cardan generator like the PRAMAC TG25/3 IP23 single/three-phase tractor-driven unit, we recommend browsing our catalog of Cardan generators to find the one that best suits your needs.
