WFM PTO Driven Generator EG 100-T2 10KVA
09455
Maximum single-phase power: 3.2 kW
Maximum single-phase power: 4 kVA
Maximum three-phase power: 8 kW
Maximum three-phase power: 10 kVA
Voltage: 230 V / 400 V
Frequency: 50 Hz
PTO speed: 430 rpm
Minimum tractor power: 30 HP
Gear ratio: 1:7
Length: 1100 mm
Width: 800 mm
Height: 910 mm
Weight: 100 kg
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 3.2
- Maximum power single phase (KVA)
- 4
- Maximum power three phase (KW)
- 8
- Maximum power three phase (KVA)
- 10
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 16A 5P CEE - 1 x 230V 16A 3P CEE
- Engine rpm (rpm)
- 3000
- Oil capacity (L)
- 0.5
- PTO speed (round/min)
- 430
- Transmission ratio
- 1 : 7
- Length (mm)
- 1100
- Width (mm)
- 800
- Height (mm)
- 910
- Dry weight (Kg)
- 100
- Inverter
- No
- AVR
- No
- Compound
- No
- Silenced
- No
- Super silenced
- No
- Brand
-
ECOGEN Series
Generators that can be connected to the tractor's PTO shaft, on a skid-mounted frame equipped with a universal three-point hitch for connection to the tractor's lift, including an electrical panel with sockets and protection as standard.
Main features:
- Frame on a skid-mounted frame
- Universal three-point hitch
- Primary Italian brand alternator with added multiplier
- Electrical panel with sockets and protection
- Full-load test with inspection certificate
- User manual compliant with safety standards
The images are purely indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
