TELWIN SUPERIOR PLASMA 70 230V/400V
816170
THIS PRODUCT IS OUT OF PRODUCTION
Phase: Single phase / Three phase
Frequency: 50/60 Hz
Voltage: 230 / 400 V
No-load voltage: 310 / 325 V
Regulation current: 20 - 50 / 20 - 70 A
Current max: 50 / 70 A
Max cutting thickness: 30 mm
Compressed air pressure: 4 - 5 bar
Length: 470 mm
Width: 190 mm
Height: 355 mm
Weight: 15.8 Kg
- Phase
- Single phase / Three phase
- Frequency (Hz)
- 50 / 60
- Voltage (V)
- 230 / 400
- Efficiency (%)
- 90
- Protection degree
- IP23
- Pressure (bars)
- 4 - 5
- No-load voltage (V)
- 310 / 325
- Regulation current (A)
- 20 - 50 / 20 - 70
- Thickest cut (mm)
- 30
- Current max (A)
- 50 / 70
- Length (mm)
- 470
- Width (mm)
- Height (mm)
- 355
- Voltage regulator
- Inverter
- Weight (Kg)
- 15.8
- EAN13
- 8004897996493
- Brand
-
Inverter, compressed air plasma cutting system, with contact striking of pilot arc.
Allows a rapid, distortion-proof cutting of all conductive materials such as steel, stainless steel, galvanised steel, aluminium, copper, brass, etc.
It allows interfacing with automated cutting systems.
Features:
- easy to carry
- high cutting current stability
- user-friendly easy to read and adjust digital panel
- remote control
- thermostatic, overvoltage, undervoltage, overcurrent, torch short circuit, phase failure protections.
Complete with torch.
Not binding images and technical data.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
