LARIUS MINIPEGASO - Cementitious materials sprayer Turbo Gun
20871
Power supply: Compressed air
Maximum water flow: 40 l/m
Tube length: from 0 to 30 mt depending on the material
Supported pipe sizes: Diam 19 x 25 Standard
Supported pipe sizes: Diam 25 x 33 Standard
Maximum fluid pressure: 7 bar
Maximum air pressure: 7 bar
Tank capacity: 50 L
Dimensions: 1000x550x950 mm
Weight: 47 Kg
Load height: 800 mm
Maximum air pressure: 8 bar 116 psi
Maximum fluid pressure (Turbo Gun): 20 bar 290 psi
Maximum fluid pressure (Tex or Hopper Gun): 10 bar 145 psi
- Pump type
- Membrane Pump
- Maximum output capacity (Lt/min)
- 40
- Pressure (bars)
- 7 max
- Tank capacity (L)
- 50
- Debris size capacity (mm)
- 3
- Acoustic pressure
- 60 dB(A)
- Length (mm)
- 1000
- Width (mm)
- 550
- Height (mm)
- 950
- Dry weight (Kg)
- 47
- Feed Type
- Aria compressa
- Version
- Trolley
- Type of pumping group
- Peristaltic Pump
- Compressor
- 1.5 kW
- Maximum fluid pressures (bar)
- 7
- Tube's lenght (Mt.)
- da 0 a 30 mt a seconda del materiale
- Product type
- Pompa
- Brand
-
Sprayer LARIUS MINIPEGASO
The MINIPEGASO equipment is a pneumatic equipment, used for spraying cement-filler materials for internal and external surfaces. Double membrane pneumatic spray pump.
The equipment requires the use of a compressor for operation.
Complete with:
-Turbo Gun with nozzles 3-4-6-8-10-12 mm
-Low pressure pipe Ø 20x26 mt.10
-Anti-stick tank lt.50
Power supply: Compressed air
Maximum water flow: 40 l/m
Tube length: from 0 to 30 mt depending on the material
Supported pipe sizes: Diam 19 x 25 Standard
Supported pipe sizes: Diam 25 x 33 Standard
Maximum fluid pressure: 7 bar
Maximum air pressure: 7 bar
Tank capacity: 50 L
Dimensions: 1000x550x950 mm
Weight: 47 Kg
Load height: 800 mm
Maximum air pressure: 8 bar 116 psi
Maximum fluid pressure (Turbo Gun): 20 bar 290 psi
Maximum fluid pressure (Tex or Hopper Gun): 10 bar 145 psi
Image and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
