Data sheet

Phase

Three phase

Maximum power three phase (KW)

25.6

Continuous power three phase (KW)

23.3

Maximum power three phase (KVA)

32

Continuous power three phase (KVA)

29

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

KUBOTA V3300-BG

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

3318

Number cylinders

4

Oil capacity (L)

13.2

Cooling

With exchanger

Alternator

Synchronous, single bearing, self-regulated, self-excited, brushless, with electronic voltage regulator

Poles

4

Bore x stroke (mm)

98 x 110

Compression ratio

22.6 : 1

Consumption (L/h)

5.6 at 50% of the load / 8 at 100% of the load

Acoustic pressure

54 dB(A) at 7 m

Length (mm)

1590

Width (mm)

700

Height (mm)

900

Dry weight (Kg)

670

Inverter

No

AVR

No

Compound

No

Silenced

Yes

Super silenced

Yes
