Data sheet

Phase

Single phase

Maximum power single phase (KW)

6

Continuous power single phase (KW)

5.4

Maximum power single phase (KVA)

6

Continuous power single phase (KVA)

5.4

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230

Engine

KUBOTA Z482

Engine rpm (rpm)

3000

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

479

Number cylinders

2

Oil capacity (L)

2.1

Cooling

With exchanger

Alternator

Synchronous, single bearing, brushless, cooled sea water

Poles

2

Bore x stroke (mm)

67 x 68

Compression ratio

23 : 1

Consumption (L/h)

1.6 at 50% of the load / 2.7 at 100% of the load

Acoustic pressure

54 dB(A) at 7 m

Length (mm)

650

Width (mm)

480

Height (mm)

530

Dry weight (Kg)

128

Inverter

No

AVR

No

Compound

No

Silenced

Yes

Super silenced

Yes
