Data sheet

Phase

Single phase

Maximum power single phase (KW)

20

Continuous power single phase (KW)

18

Maximum power single phase (KVA)

20

Continuous power single phase (KVA)

18

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230

Engine

KUBOTA V2403-BG

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

2434

Number cylinders

4

Oil capacity (L)

8

Cooling

With exchanger

Alternator

Synchronous, single bearing, self-regulated, self-excited, brushless, with electronic voltage regulator

Poles

4

Bore x stroke (mm)

87 x 102

Compression ratio

23.2 : 1

Consumption (L/h)

3.4 at 50% of the load / 6.1 at 100% of the load

Acoustic pressure

54 dB(A) at 7 m

Length (mm)

1130

Width (mm)

600

Height (mm)

700

Dry weight (Kg)

430

Inverter

No

AVR

No

Compound

No

Silenced

Yes

Super silenced

Yes
