Data sheet

Phase

Single phase

Maximum power single phase (KW)

13.3

Continuous power single phase (KW)

12

Maximum power single phase (KVA)

13.3

Continuous power single phase (KVA)

12

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230

Engine

KUBOTA D1703-BG

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

1647

Number cylinders

3

Oil capacity (L)

7

Cooling

With exchanger

Alternator

Synchronous, single bearing, self-regulated, self-excited, brushless, with electronic voltage regulator

Poles

4

Bore x stroke (mm)

87 x 92

Compression ratio

23 : 1

Consumption (L/h)

2.7 at 50% of the load / 4.2 at 100% of the load

Acoustic pressure

54 dB(A) at 7 m

Length (mm)

1060

Width (mm)

650

Height (mm)

750

Dry weight (Kg)

360

Inverter

No

AVR

No

Compound

No

Silenced

Yes

Super silenced

Yes
