MASE IS 7.1 MARINE GENERATOR SINGLE PHASE 7.1KW EPA
002725 EPA
Phase Type: Single Phase
Continuous Use Power: 6.6KW
Maximum Power: 7.1KW
Fuel: Diesel
Voltage: 120 - 240 V
Frequency: 60 Hz
Engine: Kubota Z482, 4 Stroke
Mechanical Power: 11. 1 Hp
Number of Cylinders: 2
Displacement: 479 cc
Bore x Stroke: 67 x 68 mm
Rev Regulator: Centrifugal Mechanical
Engine RPM: 3600 rpm
Sound Power: 56 dBA @ 7 m
Length: 650 mm
Width: 468 mm
Height: 555 mm
Weight: 165Kg
002725 EPA
Data sheet
- Phase
- Single phase
- Maximum power single phase (KW)
- 7.1
- Continuous power single phase (KW)
- 6.6
- Maximum power single phase (KVA)
- 7.1
- Continuous power single phase (KVA)
- 6.6
- Fuel
- Diesel
- Frequency (Hz)
- 60
- Voltage (V)
- 120 / 240
- Engine
- KUBOTA Z482, 4 stroke
- Engine rpm (rpm)
- 3600
- Speed governor
- Centrifugal, mechanical
- Engine capacity (cm³)
- 479
- Number cylinders
- 1
- Cooling
- Air / water (Intercooler W/A)
- Inyección
- Indirect
- Alternator
- Synchronous, self-excited
- Poles
- 2
- Lubrication
- Forced
- Acoustic pressure
- 56 dB(A) at 7 m
- Length (mm)
- 650
- Width (mm)
- 468
- Height (mm)
- 555
- Dry weight (Kg)
- 165
- Inverter
- No
- AVR
- No
- Compound
- No
- Silenced
- Yes
- Super silenced
- Yes
Specific References
MASE IS 7.1 SINGLE PHASE MARINE GENERATOR 7,1KW
MASE IS7,1 single phase marine generator with KUBOTA Z482 engine with diesel power supply at 3600 rpm able to deliver a power of 7,1KW.
The MASE IS7,1 is designed with a soundproof cabin that makes it supersilenced. The MASE IS7,1 marine generator is built with a diesel-powered Kubota engine and synchronous, self-excited alternator with air/water cooling. With its small size, it is also suitable on small boats.
The marine generator CBU control module has a new design, the latest technology, a large display and micro-buttons for quick navigation of menus, start and stop procedures; IP54 protection rating. Very compact, 86x124mm and equipped with 10mts shielded cable, the CBU module has multiple functions for complete monitoring of the MASE IS7.1.
The soundproof cabin of the MASE IS7,1 consists of a supporting structure in aluminum profile that supports panels in marine aluminum painted type 5754 extremely light and very high resistance to external agents. The excellent accessibility to the internal compartment makes maintenance operations easier, even when the generator set is installed in narrow spaces.
The MASE IS7.1 marine generator has EPA certification valid only for the U.S. market.
Technical features:
Maximum power: 7.1 KW
Continuous use power: 6. 6 KW
Fuel: Diesel
Voltage: 120 V / 240 V
Frequency: 60 Hz
Motor: KUBOTA Z482
Length: 650 mm
Width: 468 mm
Height: 555 mm
Weight: 165 Kg
If you are looking for another generator like the MASE IS7,1 then you can browse the entire catalog of marine gensets.
Images and technical data are not binding.
