KOHLER 70EFOZDJ THREE-PHASE MARINE GENERATOR 70 kW
Phase Type: Single Phase/Three Phase
Continuous Power: 70 KW
Continuous Power: 88 KVA
Motor: 4 Stroke
Number of cylinders: 4
Fuel: Diesel
Frequency: 50 Hz
Voltage: 110/190 V, 110/220 V, 120/208 V, 220/380 V, 230/400 V, 240/416 V
Electrical system 12v or 24v c. c.
Motor speed: 1500 rpm
Cooling: Heat exchanger
Consumption: 18.88 l/h @ 75%
Length: 1754 mm
Width: 831 mm
Height: 1032 mm
Dry weight: 1234 Kg
70EFOZDJ
Data sheet
- Phase
- Single phase / Three phase
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Engine
- 4 Stroke
- Emissions Regulations
- Tier III
- Engine rpm (rpm)
- 1500
- Speed governor
- Electronic
- Number cylinders
- 4
- Cylinders' position
- In line
- Cooling
- With exchanger
- Inyección
- Direct
- Alternator
- Permanent magnets
- Poles
- 4
- Bore x stroke (mm)
- 107 X 127
- Compression ratio
- 16.7:1
- Nominal power continuous
- 70 KW
- Motor insulation class
- H
- Consumption (L/h)
- 18.88 @ 75%
- Length (mm)
- 1754
- Width (mm)
- 831
- Height (mm)
- Dry weight (Kg)
- 1234
- Silenced
- Yes
- Super silenced
- Yes
- Brushes
- No
- PMG
- Yes
- Input voltage (V)
- 12 or 24
- Type of combustion
- Direct
- Product type
- Generator
- Type of alternator
- Constant Speed
- Voltage regulator
- AVR
Specific References
New
KOHLER 70EFOZDJ THREE-PHASE MARINE ELECTRIC GENERATOR 70 kW
KOHLER 70EFOZDJ is a 70 KW three-phase marine generator equipped with a 1500 rpm Diesel powered engine and parallel panel. The KOHLER 70EFOZDJ marine generator is built with a soundproof aluminum enclosure that makes it supersilenced. The KOHLER 70EFOZDJ marine generator is built with a 4-cylinder diesel-powered engine. The alternator of the KOHLER 70EFOZDJ marine generator is brushless with AVR voltage regulator and water-cooled. Suitable for parallel mounting on large boats.
Technical Data KOHLER 70EFOZDJ:
Phase Type: Single Phase/Three Phase
Continuous Power: 70 KW
Continuous Power: 88 KVA
Motor: 4 Stroke
Number of cylinders: 4
Fuel: Diesel
Frequency: 50 Hz
Voltage: 110/190 V, 110/220 V, 120/208 V, 220/380 V, 230/400 V, 240/416 V
Electrical system 12v or 24v c. c.
Motor speed: 1500 rpm
Cooling: Heat exchanger
Consumption: 18.88 l/h @ 75%
Length: 1754 mm
Width: 831 mm
Height: 1032 mm
Dry weight: 1234 Kg
Features of the KOHLER marine generator
- Aluminium soundproof cabin
- 5''Acqualift exhaust silencer
- DEC3500+ Controller and digital display with full monitoring of all AC alarms and functions including also Fail Safe circuit, interface with on-board computer and ModBus connection
- Overspeed and overvoltage protection
- 5''Exhaust gas separator
- Power circuit breaker
- Control system with pre-alarm and alarm-ù- Stop system for BPO, ATA and overspeed
- Cooled exhaust curve
- Exchanger water level alarm
- Oil level alarm in sump
- Crank-vent oil vapour separator
- New model supports, Focused Mounts
- Insulated Poles Kit
- Manual and automatic parallel predisposition kit installed and tested on our test bench (excluding components of the control panel). test bench (excluding components for the parallel panel)
- Double cased diesel pipes as per specific classification body.
If you are looking for marine generators such as KOHLER 70EFOZDJ but with different features you can see the entire catalog of marine generators.
Pictures and technical data not binding.
