CGM 12.5DE - APERTO CON CENTRALINA AUTOMATICA
CGM 15LW COFANATO MANUALE /
OUT OF STOCK
Maximum three-phase power: 13.2 KW
Continuous three-phase power: 12 KW
Maximum three-phase power: 16.5 KVA
Continuous three-phase power: 15 KVA
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Current A: 22 A
Power factor cos: 0.80
Socket configuration: N.1 400 V 5P 32A / N.1 230 V 3P 16A
Electrical protection: IP44
Motor: KOHLER KDW1603
Displacement cc: 1649
Engine rpm: 1500 rpm
Bore x stroke : 75 x 77.6
Aspiration: Aspirated
Speed ??regulator: Mechanical
Number and arrangement of cylinders: 3 in line
Cooling system: Water
Starting: Electric
Alternator: Linz, with brushes
Poles: 4
Voltage regulator system: Compound
Consumption: 3.3 Lt / h at 75% of the load
Tank capacity: 50 Lt
Autonomy: 15.1 h at 75% of the load
Acoustic pressure: 67 dB (A) at 7 meters
Length: 1600 mm
Width: 700 mm
Height: 1050 m m
Weight: 495 Kg
- Phase
- Single phase / Three phase
- Maximum power three phase (KW)
- 13.2
- Continuous power three phase (KW)
- 12
- Maximum power three phase (KVA)
- 16.5
- Continuous power three phase (KVA)
- 15
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Engine
- KOHLER KDW1603
- Engine rpm (rpm)
- 1500
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 1649
- Number cylinders
- 3
- Cylinders' position
- In line
- Cooling
- Water
- Alternator
- With brushes
- Poles
- 4
- Protection degree
- IP44
- Bore x stroke (mm)
- 75 x 77.6
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
