CGM 12.5DE - APERTO CON CENTRALINA AUTOMATICA
CGM 15DET COFANATO MANUALE /
OUT OF PRODUCTION
- Phase
- Single phase / Three phase
- Protection degree
- IP55
- Height (mm)
- 1150
- Length (mm)
- 1450
- Starting system
- Electric
- Width (mm)
- 800
- Engine manufacturer
- Kohler
- Engine
- KOHLER 25LD 425/2
- Poles
- 2
- Sockets configuration
- 1 x 400V 32A 5P CEE - 1 x 230V 16A 3P CEE
- Cooling
- Air
- Maximum power three phase (KW)
- 13.2
- Continuous power three phase (KW)
- 12
- Maximum power three phase (KVA)
- 16.5
- Continuous power three phase (KVA)
- 15
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 240
- Engine rpm (rpm)
- 3000
- Engine capacity (cm³)
- 954
- Number cylinders
- 2
- Oil capacity (L)
- 2.5
- Alternator
- With brushes
- Fuel tank capacity (L)
- 50
- Consumption (L/h)
- 3.2
- Running time (h)
- 15.6
- Acoustic pressure
- 73 dB(A) at 7 m
- Dry weight (Kg)
- 360
- Silenced
- No
- Super silenced
- No
- ATS Switch device
- No ATS
- Voltage regulator
- Compound
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
