PRAMAC GBW45Y APERTO CON QUADRO COMANDO MANUALE (MCP)
SH450TYAI00 /
OUT OF PRODUCTION
Maximum power Three-phase: 36.68 KW
Power continuous use Three-phase: 34.82 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98T-GPGE STAGE II
Starting: Electric
Consumption: 10.9 Lt/h at 100% of the load
Length: 2000 mm
Width: 920 mm
Height: 1100 mm
Weight: 611 Kg
AVR
- Phase
- Three phase
- Maximum power three phase (KW)
- 36.68
- Continuous power three phase (KW)
- 34.82
- Maximum power three phase (KVA)
- 45.85
- Continuous power three phase (KVA)
- 43.52
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 32A 3P+N+T CEE - 1 x 400V 16A 3P+N+T CEE - 2 x 230V 16A 2P+T CEE - 1 x 230V 16A SCHUKO
- Engine
- Yanmar 4TNV98T-GPGE, turbocharged
- Emissions Regulations
- Stage 2
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 3319
- Number cylinders
- 4
- Cylinders' position
- In line
- Oil capacity (L)
- 10.5
- Cooling
- Water
- Alternator
- Mecc Alte ECO/P32-3S/4, brushless
- Poles
- 4
- Fuel tank capacity (L)
- 51
- Consumption (L/h)
- 8.2 at 75% of the load / 10.9 at 100% of the load
- Running time (h)
- 6.2 at 75% of the load / 4.7 at 100% of the load
- Length (mm)
- 2000
- Width (mm)
- 920
- Height (mm)
- 1100
- Dry weight (Kg)
- 611
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- No ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Yanmar
- Brand
-
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
