TECNOGEN H2700


Phase
Single phase / Three phase
Height (mm)
920
Length (mm)
1070
Starting system
Electric
Width (mm)
560
Engine manufacturer
Yanmar
Engine
HONDA GC160
Cooling
Air
Maximum power single phase (KW)
3
Maximum power single phase (KVA)
3.8
Maximum power three phase (KW)
5
Maximum power three phase (KVA)
6.3
Fuel
Diesel
Frequency (Hz)
50
Voltage (V)
230 / 400
Engine rpm (rpm)
3000
Engine capacity (cm³)
406
Number cylinders
1
Fuel tank capacity (L)
20
Consumption (L/h)
1.4 at 75% of the load
Running time (h)
14.29 at 75% of the load
Acoustic power
93 dB(A)
Dry weight (Kg)
190
Silenced
No
Super silenced
Yes
ATS Switch device
ATS Included
Voltage regulator
No
Brand

* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
