MASE MPV 22 BA
007852
OUT OF PRODUCTION
Single-phase maximum power: 13.5 KW
Three-phase maximum power: 17.6 KW
Three-phase continuous use power: 16 KW
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Engine: Yanmar 3TNV88
Starting: Electric
Consumption: 2.5 Lt / h at 75% of the load
Length: 1750 mm
Width: 800 mm
Height: 900 mm
Weight: 600 Kg
Compound
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 13.5
- Maximum power single phase (KVA)
- 13.5
- Maximum power three phase (KW)
- 17.6
- Continuous power three phase (KW)
- 16
- Maximum power three phase (KVA)
- 22
- Continuous power three phase (KVA)
- 20
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 2 x 230V 16A CE
- Engine
- Yanmar 3TNV88, 4 stroke
- Engine rpm (rpm)
- 1500
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 2190
- Number cylinders
- 4
- Oil capacity (L)
- 7.4
- Cooling
- Water
- Inyección
- Direct
- Alternator
- Synchronous self-excited, with brushes
- Poles
- 4
- Lubrication
- Forced
- Fuel tank capacity (L)
- 50
- Consumption (L/h)
- 2.5 at 75% of the load
- Running time (h)
- 20 at 75% of the load
- Acoustic power
- 94 dB(A)
- Length (mm)
- 1750
- Height (mm)
- 900
- Dry weight (Kg)
- 600
- Silenced
- Yes
- Super silenced
- Yes
- ATS Switch device
- Optional ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Yanmar
- Brand
-
OUT OF PRODUCTION
Single-phase maximum power: 13.5 KW
Three-phase maximum power: 17.6 KW
Three-phase continuous use power: 16 KW
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Engine: Yanmar 3TNV88
Starting: Electric
Consumption: 2.5 Lt / h at 75% of the load
Length: 1750 mm
Width: 800 mm
Height: 900 mm
Weight: 600 Kg
Compound
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
