WFM SP7500-TDSE Generator Set 6.4KVA AVR
Maximum power Single-phase: 3 KW
Maximum single-phase power: 3.8 KVA
Maximum three-phase power: 5.1 KW
Maximum three-phase power: 6.4 KVA
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Engine: Lombardini 15LD440
Starting: Electric
Consumption: 2 Lt at 100% load
Length: 750 mm
Width: 560 mm
Height: 620 mm
Weight: 170 Kg
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 3
- Maximum power single phase (KVA)
- 3.8
- Maximum power three phase (KW)
- 5.1
- Maximum power three phase (KVA)
- 6.4
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 32A 5P CEE - 1 x 230V 16A 3P CEE - 1 x 230V 16A 3P SCHUKO
- Engine
- LOMBARDINI 15LD440
- Engine rpm (rpm)
- 3000
- Starting system
- Elettrico
- Engine capacity (cm³)
- 436
- Number cylinders
- 1
- Oil capacity (L)
- 2
- Cooling
- Air
- Fuel tank capacity (L)
- 20
- Consumption (L/h)
- 2 at 100% of the load
- Running time (h)
- 10 at 100% of the load
- Acoustic power
- 96 dB(A)
- Acoustic pressure
- 71 dB(A) at 7 m
- Length (mm)
- 750
- Width (mm)
- 560
- Height (mm)
- 620
- Dry weight (Kg)
- 170
- Silenced
- Yes
- Super silenced
- No
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- LOMBARDINI
WFM SP7500-TDSE Generator Set 6.4KVA AVR
WFM SP7500-TDSE AVR GENERATOR: The power you need, wherever you need it
The WFM SP7500-TDSE GENERATOR AVR is a powerful and versatile generator set, ideal for powering your electronic equipment in any situation.
Thanks to its AVR (Automatic Voltage Regulator) technology, this generator guarantees a stable and precise voltage,
protecting your devices from power surges that could cause damage.
Strong points:
AVR technology: AVR voltage stabilisation protects your electronic equipment, even the most sensitive, from current surges.
Versatility: Suitable for both domestic and professional use, ideal for powering inverter welders, power tools, computers, TVs, and more.
Power: With a maximum power output of 6.4 KVA, it can also power several devices simultaneously.
Reliability: Lombardini diesel engine, a guarantee of quality and durability.
Ease of use: Electric start with battery, ready to use at any time.
Safety: Low oil level protection and muffler for safe and silent operation.
Transportability: Compact size and low weight for easy transport.
Technical specifications WFM SP7500-TDSE AVR GENERATOR
Maximum power Single-phase: 3 KW
Maximum single-phase power: 3.8 KVA
Maximum three-phase power: 5.1 KW
Maximum three-phase power: 6.4 KVA
Fuel: Diesel
Voltage: 230 V / 400 V
Frequency: 50 Hz
Engine: Lombardini 15LD440
Starting: Electric
Consumption: 2 Lt at 100% load
Length: 750 mm
Width: 560 mm
Height: 620 mm
Weight: 170 Kg
if you are looking for a product with similar characteristics CLICK HERE.
Images are purely indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
