PRAMAC GSL30D COFANATO CON QUADRO COMANDO AUTOMATICO
SU290TDAT02 /
OUT OF PRODUCTION
Maximum power Three-phase: 25.55 KW
Three-phase continuous use power: 24.31 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Deutz AG F4M2011
Starting: Electric
Consumption: 8 Lt/h at 100% of the load
Length: 2005 mm
Width: 948 mm
Height: 1308 mm
Weight: 760 Kg
AVR
- Phase
- Three phase
- Maximum power three phase (KW)
- 25.55
- Continuous power three phase (KW)
- 24.31
- Maximum power three phase (KVA)
- 31.94
- Continuous power three phase (KVA)
- 30.39
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 63A 3P+N+T CEE
- Engine
- Deutz AG F4M2011, naturally aspirated
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 3110
- Number cylinders
- 4
- Cylinders' position
- In line
- Oil capacity (L)
- 10
- Cooling
- Oil
- Alternator
- Mecc Alte ECP28-VL/4, brushless
- Poles
- 4
- Fuel tank capacity (L)
- 68
- Consumption (L/h)
- 5.7 at 75% of the load / 8 at 100% of the load
- Running time (h)
- 11.9 at 75% of the load / 8.4 at 100% of the load
- Acoustic power
- 89 dB(A)
- Acoustic pressure
- 60 dB(A) at 7 m
- Length (mm)
- 2005
- Width (mm)
- 948
- Height (mm)
- 1308
- Dry weight (Kg)
- 760
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Deutz
- Brand
-
Motore Diesel. Predisposto per Biodiesel. Raffreddamento ad olio con radiatore. Silenziatore industriale. Base forcabile con carrelli. Liquidi motore e batteria carica
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
