PRAMAC GBW45Y APERTO CON QUADRO COMANDO AUTOMATICO
SH450TYAI02 /
OUT OF PRODUCTION
Maximum power Three-phase: 36.68 KW
Power continuous use Three-phase: 34.82 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98T-GPGE
Starting: Electric
Consumption: 10.9 Lt/h at 100% of the load
Length: 2000 mm
Width: 920 mm
Height: 1100 mm
Weight: 611 Kg
AVR
- Phase
- Three phase
- Maximum power three phase (KW)
- 36.68
- Continuous power three phase (KW)
- 34.82
- Maximum power three phase (KVA)
- 45.85
- Continuous power three phase (KVA)
- 43.52
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 32A 3P+N+T CEE
- Engine
- Yanmar 4TNV98T-GPGE, turbocharged
- Emissions Regulations
- Stage 2
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 3319
- Number cylinders
- 4
- Cylinders' position
- In line
- Oil capacity (L)
- 10.5
- Cooling
- Water
- Alternator
- Mecc Alte ECO/P32-3S/4, brushless
- Poles
- 4
- Fuel tank capacity (L)
- 51
- Consumption (L/h)
- 8.2 at 75% of the load / 10.9 at 100% of the load
- Running time (h)
- 6.2 at 75% of the load / 4.7 at 100% of the load
- Length (mm)
- 2000
- Width (mm)
- 920
- Height (mm)
- 1100
- Dry weight (Kg)
- 611
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Yanmar
- Brand
-
Motore Diesel. Raffreddamento ad acqua. Silenziatore industriale. Base forcabile con carrelli. Liquidi motore e batteria carica. Quadro manuale MCP fornito di serie con 5 prese
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
