PRAMAC GBW22P GENSET WITH AUTOMATIC CONTROL PANEL
SH200TPAL02 /
OUT OF PRODUCTION
Maximum power Three-phase: 17.46 KW
Three-phase continuous use power: 15.82 KW
Fuel: Diesel
Voltage: 400 V
Frequency: 50 Hz
Engine: Perkins 404D-22G
Starting: Electric
Consumption: 5.3 Lt/h at 100% of the load
Length: 1600 mm
Width: 870 mm
Height: 950 mm
Weight: 425 Kg
Compound
- Phase
- Three phase
- Maximum power three phase (KW)
- 17.46
- Continuous power three phase (KW)
- 15.42
- Maximum power three phase (KVA)
- 21.82
- Continuous power three phase (KVA)
- 19.78
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 400
- Sockets configuration
- 1 x 400V 32A 3P+N+T CEE
- Engine
- PERKINS 404D-22G, naturally aspirated
- Emissions Regulations
- Stage 3A
- Speed governor
- Mechanical
- Starting system
- Electric
- Engine capacity (cm³)
- 2216
- Number cylinders
- 4
- Cylinders' position
- In line
- Oil capacity (L)
- 10.6
- Cooling
- Water
- Alternator
- Linz E1S13MF, with brushes
- Poles
- 4
- Fuel tank capacity (L)
- 51
- Consumption (L/h)
- 4 at 75% of the load / 5.3 at 100% of the load
- Running time (h)
- 12.8 at 75% of the load / 9.7 at 100% of the load
- Length (mm)
- 1600
- Width (mm)
- 870
- Height (mm)
- 950
- Dry weight (Kg)
- 425
- Silenced
- No
- Super silenced
- No
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- Compound
- Engine manufacturer
- Perkins
- Brand
-
La serie GBW offre macchine affidabili e potenti, costruite per l'uso professionale in supporto alla rete elettrica in caso di black out o per servire luoghi isolati.
Facili da trasportare, installare e posizionare grazie alla dimensione compatta, questo modello è ideale per l'emergenza rete, edilizia, officine mobili e applicazioni industriali.
Disponiblie in versione aperta o cofanata.
? Motori diesel YANMAR/PERKINS
? Raffreddamento ad acqua
? Silenziatore industriale
? Base forcabile con carrelli
? Liquidi motore e batteria carica
? Quadro manuale MCP fornito di serie con 5 prese.
Le immagini sono puramente indicative.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
