GENSET MG 50 I-SY - SINGLE-PHASE/THREE-PHASE GENERATOR 44 KVA AVR
MG 50 I-SY
Maximum power Three-phase: 44 KVA
Maximum power Three-phase: 35.2 KW
Power continuous use Three-phase: 39.6 KVA
Power continuous use Three-phase: 31.68 KW
Maximum power Single-phase: 14.6 KVA
Maximum power Single-phase: 11.68 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98T (STAGE V)
Starting: Electric
Consumption: 8.1 Lt/h
Tank: 40 lt
Length: 1900 mm
Width: 910 mm
Height: 1100 mm
Weight: 735 Kg
Super silenced
AVR
- Phase
- Single phase / Three phase
- Maximum power single phase (KW)
- 11.68
- Maximum power single phase (KVA)
- 14.6
- Maximum power three phase (KW)
- 35.2
- Continuous power three phase (KW)
- 31.68
- Maximum power three phase (KVA)
- 44
- Continuous power three phase (KVA)
- 39.6
- Fuel
- Diesel
- Frequency (Hz)
- 50
- Voltage (V)
- 230 / 400
- Sockets configuration
- 1 x 400V 63A CEE - 1 x 400V 32A CEE - 1 x 230V 32A CEE - 230V 16A CEE
- Engine
- Yanmar 4TNV98T, 4 stroke
- Emissions Regulations
- Stage 5
- Engine rpm (rpm)
- 1500
- Starting system
- Electric
- Engine capacity (cm³)
- 3319
- Number cylinders
- 4
- Cooling
- Water
- Alternator
- Synchronous
- Protection degree
- IP23
- Motor insulation class
- H
- Fuel tank capacity (L)
- 40
- Consumption (L/h)
- 8.1
- Running time (h)
- 4.94
- Acoustic power
- 95 dB(A)
- Acoustic pressure
- 70 dB(A) at 7 m
- Length (mm)
- 1900
- Width (mm)
- 910
- Height (mm)
- 1100
- Dry weight (Kg)
- 735
- Silenced
- Yes
- Super silenced
- Yes
- Product type
- Generator
- ATS Switch device
- Optional ATS
- Voltage regulator
- AVR
- Engine manufacturer
- Yanmar
- Brand
-
GENSET MG 50 I-SY - SINGLE-PHASE- THREE-PHASE ELECTRIC GENERATOR 44 KVA AVR Stage 5
The three-phase 44 KVA diesel generator is the ideal solution for those who need a reliable and powerful energy source in professional or domestic contexts.
Main features GENSET MG 50 I-SY:
High power:
Maximum three-phase power: 44 KVA (35.2 kW)
Three-phase continuous power: 39.6 KVA (31.68 kW)
Single-phase maximum power: 14.6 KVA (11.68 kW)
Yanmar 4TNV98T (STAGE V) engine: 4-cylinder liquid-cooled diesel engine,
reliable and high-performance, complying with STAGE V emission standards.
Electric start: Quick and easy starting with key.
Efficient consumption: Low fuel consumption (8.1 Lt/h) for optimum range.
Super silent: Soundproof design for quiet operation.
Robust construction: Compact and robust design for easy transport and storage.
Technical characteristics GENSET MG 50 I-SY
Maximum power Three-phase: 44 KVA
Maximum power Three-phase: 35.2 KW
Power continuous use Three-phase: 39.6 KVA
Power continuous use Three-phase: 31.68 KW
Maximum power Single-phase: 14.6 KVA
Maximum power Single-phase: 11.68 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98T (STAGE V)
Starting: Electric
Consumption: 8.1 Lt/h
Tank: 40 lt
Length: 1900 mm
Width: 910 mm
Height: 1100 mm
Weight: 735 Kg
Super silenced
AVR
If you are looking for a product like GENSET MG 50 I-SY with different characteristics click HERE.
Images and technical data are not binding.
* Images and technical data are not binding. Please always consult the technical data sheet released by the manufacturer. Manel Service does not assume responsibility for any changes made by the manufacturer.
