GREEN POWER GP145 S/B-A SOUNDPROOF Not Emissioned

GREEN POWER GP145S-B-N SILENT

The 1500 rpm three-phase diesel generator represents a reliable and high-performance solution for industrial, construction site, and power continuity applications. Designed to ensure high efficiency and long-lasting durability, it is equipped with a Baudouin 6M11G150-5 6-cylinder engine and a Baudouin 6M11G2D0/S alternator, synonymous with quality and robustness.

The maximum three-phase power reaches 118 kW (148 kVA), while the continuous power is 108 kW (135 kVA), making it ideal for prolonged use and constant loads. The system operates at 50 Hz with 230/400 V voltage, ensuring compatibility with most European industrial systems.

Equipped with an electronic speed governor and electric start, it ensures precision and ease of use. The 160-liter tank allows for good operating autonomy, with a consumption of 23.1 L/h at 75% load.

The structure is completely silenced and in a super silenced version, ideal for contexts where low noise impact is required. The unit has compact dimensions (3000 x 1100 x 1520 mm) and a dry weight of 1850 kg, making it easy to install and handle.

It is also designed for integration with an optional ATS (Automatic Transfer Switch) switchboard to ensure automatic power continuity in the event of a blackout.

Main features:

Phase type Single-phase / Three-phase

Maximum three-phase power (KW):118

Continuous three-phase power (KW): 108

Maximum three-phase power (KVA): 148

Continuous three-phase power (KW): 108

Continuous three-phase power (KVA): 148

Continuous continuous three-phase (KVA): 135

Fuel: Diesel

Frequency (Hz): 50

Voltage (V): 230 / 400

Engine: Baudouin 6M11G150-5

Engine speed (rpm): 1500

Speed ​​governor: Electronic

Starter: Electric

Displacement (cm³): 6750

Number of cylinders: 6

Alternator: MECC ALTE ECP34-2M/4

Number of poles: 4

Fuel tank capacity (L): 160

Consumption (L/h): 23.1 Lt/h at 75% load

Length (mm): 3000

Width (mm): 1100

Height (mm): 1520

Dry weight (Kg): 1850

Silenced: Yes

Super silenced: Yes

ATS switch panel: Optional

Emissions Regulation: Not Emitted
