Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

1100

Continuous power three phase (KW)

1000

Maximum power three phase (KVA)

1375

Continuous power three phase (KVA)

1250

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

PERKINS 403A-11G

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

45842

Number cylinders

12

Cylinders' position

V 60°

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Protection degree

IP44

Bore x stroke (mm)

160 x 190

Fuel tank capacity (L)

400

Consumption (L/h)

196

Running time (h)

2 al 75% del carico

Length (mm)

4900

Width (mm)

2100

Height (mm)

2400

Dry weight (Kg)

9700

Silenced

No

Super silenced

No

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins
