Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

1000

Continuous power three phase (KW)

900

Maximum power three phase (KVA)

1250

Continuous power three phase (KVA)

1125

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

PERKINS 403A-11G

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

1131

Number cylinders

8

Cylinders' position

In line

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Protection degree

IP44

Bore x stroke (mm)

160 x 190

Fuel tank capacity (L)

400

Consumption (L/h)

188

Running time (h)

2.1

Length (mm)

4900

Width (mm)

2100

Height (mm)

2400

Dry weight (Kg)

8000

Silenced

No

Super silenced

No

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins
