Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

8.8

Continuous power three phase (KW)

8

Maximum power three phase (KVA)

11

Continuous power three phase (KVA)

10

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 x 400V 32A 5P CEE - 1 x 230V 16A 3P CEE

Engine

Lombardini LDW702

Engine rpm (rpm)

3000

Starting system

Electric

Engine capacity (cm³)

686

Number cylinders

2

Cylinders' position

In line

Cooling

Water

Alternator

With brushes

Poles

2

Protection degree

IP44

Bore x stroke (mm)

75 x 77.6

Fuel tank capacity (L)

50

Consumption (L/h)

2.9 at 75% of the load

Running time (h)

17.2

Length (mm)

1600

Width (mm)

700

Height (mm)

1050

Dry weight (Kg)

290

Silenced

Yes

Super silenced

Yes

ATS Switch device

No

Voltage regulator

Compound

Engine manufacturer

Lombardini
