Data sheet

Phase

Single phase / Three phase

Maximum power three phase (KW)

35.2

Continuous power three phase (KW)

32

Maximum power three phase (KVA)

44

Continuous power three phase (KVA)

40

Fuel

Natural Gas

Frequency (Hz)

50

Voltage (V)

230 / 400

Engine

General Motors RMG 4300

Engine rpm (rpm)

1500

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

4300

Number cylinders

6

Cooling

Water

Alternator

Marelli, brushless

Poles

4

Bore x stroke (mm)

101.6 x 91.4

Natural Gas consumption (m³/h)

13.5 at 100% of the load

Length (mm)

1800

Width (mm)

900

Dry weight (Kg)

880

Silenced

No

Super silenced

No

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

General Motors
