GENSET MGF 33 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 33 KVA AVR

Name: GENSET MGF 33 Y - SINGLE-PHASE/THREE-PHASE GENERATOR 33 KVA AVR
Brand: GENSET
SKU: MGF 33 Y
Price: 11488.01 EUR
Availability: InStock

Reference MGF 33 Y

Maximum power Three-phase: 33 KVA
Maximum power Three-phase: 26.4 KW
Maximum power Single-phase: 11 KVA
Maximum power Single-phase: 8.8 KW
Fuel: Diesel
Voltage: 230/400 V
Frequency: 50 Hz
Engine: Yanmar 4TNV98 (STAGE 0)
Starting: Electric
Consumption: 6.4 Lt/h
Length: 1640 mm
Width: 770 mm
Height: 1076 mm
Weight: 830 Kg
Super silenced
AVR

List price

20,496.00 € tax incl.

16,800.00 € tax excl.

Discounted Price

11,488.01 € tax incl.

9,416.40 € tax excl.

Shipping from 292.80 € to Italy buy it today. tax incl.

Calculate Shipping Cost

Payment methods:

Full Name

City

Country

Company

Phone

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

Offer on letterhead

Name

Surname

Company

VAT

Shipping address

Phone

City

Country

Postal code

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference MGF 33 Y

Data sheet

Phase: Three phase
Maximum power three phase (KVA): 33
Continuous power three phase (KVA): 30
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 400
Sockets configuration
Engine: Yanmar 4TNV98, 4 stroke
Emissions Regulations: Stationary Use
Engine rpm (rpm): 1500
Starting system: Electric
Engine capacity (cm³): 3319
Number cylinders: 4
Cooling: Water
Protection degree: IP23
Motor insulation class: H
Fuel tank capacity (L): 40
Consumption (L/h): 6.4
Running time (h): 6.25
Acoustic power: 97 dB(A)
Acoustic pressure: 72 dB(A) at 7 m
Length (mm): 1640
Width (mm): 770
Height (mm): 1076
Dry weight (Kg): 830
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: Optional
Voltage regulator: AVR
Engine manufacturer: Yanmar

Specific References

Condition New

GENSET MGF 33 Y

The GENSET MGF 33 Y is a single-phase/three-phase 33 KVA diesel generator with electric start and AVR voltage regulator.
Thanks to its compact size and its very low weight, the GENSET MGF 33 Y is a light and easy to transport generator.
The GENSET MGF 33 Y also has a low fuel consumption: only 6.4 Lt/h at 75% of the load.
The GENSET MGF 33 Y generator set, thanks to the high quality and efficiency of its components, is ideal for various types of work: from small hobby jobs to large construction sites.

Images and technical data are not binding.

* Images and technical data are not binding. Please always consult the manufacturer's technical data sheet. Manel Service assumes no responsibility for any changes made by the manufacturer or any typographical errors.
