Data sheet

Phase

Single phase / Three phase

Maximum power single phase (KW)

9.5

Continuous power single phase (KW)

6.8

Maximum power single phase (KVA)

9.1

Continuous power single phase (KVA)

8.5

Maximum power three phase (KW)

12.6

Continuous power three phase (KW)

9.6

Maximum power three phase (KVA)

15.8

Continuous power three phase (KVA)

12

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

230 / 400

Sockets configuration

1 x 400V 16A 3P+N+T CEE - 1 x 230V 32A 2P+T CEE - 1 x 230V 16A 2P+T CEE

Engine

Hatz 2G40, naturally aspirated

Engine rpm (rpm)

3000

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

997

Oil capacity (L)

2.5

Cooling

Air

Poles

2

Fuel tank capacity (L)

17

Consumption (L/h)

2.74 at 75% of the load / 3.66 at 100% of the load

Running time (h)

6.20 at 75% of the load / 4.64 at 100% of the load

Acoustic power

97 dB(A)

Acoustic pressure

69 dB(A) at 7 m

Length (mm)

1270

Width (mm)

610

Height (mm)

816

Dry weight (Kg)

275

Silenced

Yes

Super silenced

No

Product type

Generator

ATS Switch device

No

Voltage regulator

Compound

Engine manufacturer

Hatz
