Data sheet

Phase

Three phase

Maximum power three phase (KW)

118.4

Continuous power three phase (KW)

112.32

Maximum power three phase (KVA)

148

Continuous power three phase (KVA)

140.4

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

PERKINS 1006 TAG, turbocharged

Speed governor

Electronic

Starting system

Electric

Engine capacity (cm³)

5990

Number cylinders

6

Cylinders' position

In line

Oil capacity (L)

19

Cooling

Water

Alternator

Mecc Alte ECP34-1L, brushless

Poles

4

Fuel tank capacity (L)

250

Consumption (L/h)

24.4 at 75% of the load / 31.5 at 100% of the load

Running time (h)

10.2 at 75% of the load / 7.9 at 100% of the load

Length (mm)

2600

Width (mm)

1000

Height (mm)

1600

Dry weight (Kg)

1417

Silenced

No

Super silenced

No

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins
