Data sheet

Phase

Three phase

Maximum power three phase (KW)

88.7

Continuous power three phase (KW)

80.67

Maximum power three phase (KVA)

110.87

Continuous power three phase (KVA)

100.84

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Engine

FPT NEF45TM2A, turbo aftercooler

Emissions Regulations

Stage 2

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

4500

Number cylinders

4

Cylinders' position

In line

Oil capacity (L)

12.8

Cooling

Water

Alternator

Mecc Alte ECP34-2S/4, brushless

Poles

4

Fuel tank capacity (L)

350

Consumption (L/h)

16.3 at 75% of the load / 22.1 at 100% of the load

Running time (h)

21.5 at 75% of the load / 15.8 at 100% of the load

Acoustic power

96 dB(A)

Acoustic pressure

67 dB(A) at 7 m

Length (mm)

3000

Width (mm)

1150

Height (mm)

1760

Dry weight (Kg)

1684

Silenced

Yes

Super silenced

Yes

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

FPT Iveco
