Data sheet

Phase

Three phase

Maximum power three phase (KW)

26

Continuous power three phase (KW)

24.4

Maximum power three phase (KVA)

32.5

Continuous power three phase (KVA)

30.5

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Sockets configuration

1 x 400V 32A 3P+N+T CEE

Engine

PERKINS 1103A-33G, naturally aspirated

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

3300

Number cylinders

3

Cylinders' position

In line

Oil capacity (L)

8.3

Cooling

Water

Alternator

Mecc Alte ECP28-VL/4, brushless

Poles

4

Fuel tank capacity (L)

51

Consumption (L/h)

5.4 at 75% of the load / 7.1 at 100% of the load

Running time (h)

9.4 at 75% of the load / 7.2 at 100% of the load

Length (mm)

2000

Width (mm)

920

Height (mm)

1100

Dry weight (Kg)

700

Silenced

No

Super silenced

No

Product type

Generator

ATS Switch device

Optional

Voltage regulator

AVR

Engine manufacturer

Perkins
