Data sheet

Phase

Three phase

Maximum power three phase (KW)

11.44

Continuous power three phase (KW)

10.4

Maximum power three phase (KVA)

14.3

Continuous power three phase (KVA)

13

Fuel

Diesel

Frequency (Hz)

50

Voltage (V)

400

Sockets configuration

1 x 400V 32A 3P+N+T CEE

Engine

Yanmar 3TNV88-BGPGE, naturally aspirated

Emissions Regulations

Stage 5

Engine rpm (rpm)

1500

Speed governor

Mechanical

Starting system

Electric

Engine capacity (cm³)

1642

Number cylinders

3

Cylinders' position

In line

Oil capacity (L)

6.9

Cooling

Water

Alternator

Linz E1S13MD, with brushes

Poles

4

Fuel tank capacity (L)

51

Consumption (L/h)

2.8 at 75% of the load / 3.8 at 100% of the load

Running time (h)

18 at 75% of the load / 13.5 at 100% of the load

Length (mm)

1600

Width (mm)

870

Height (mm)

950

Dry weight (Kg)

390

Silenced

No

Super silenced

No

Product type

Generator

ATS Switch device

Optional

Voltage regulator

Compound

Engine manufacturer

Yanmar
