VISA SMARTGENSET K15SG SINGLE-PHASE/ THREE-PHASE GENERATOR 17KVA

VISA SMARTGENSET K15SG SINGLE-PHASE/ THREE-PHASE GENERATOR 17KVA

OUT OF PRODUCTION

Phase Type: Single Phase / Three Phase
Single Phase Continuous Power: 5 KVA / 4 KW
Single Phase Maximum Power: 5.7 KVA / 4. 5 KW
Three-phase Continuous Power: 15 KVA / 12 KW
Three-phase Maximum Power: 17 KVA / 13 KW
Motor: Kholer KDW1603
Power Supply: Diesel
Motor RPM: 1500 rpm
RPM Adjustment: Mechanical
Alternator: STAMFORD S0L1-P1
Voltage regulator: AVR
Voltage: 230 / 400 V
Frequency: 50 Hz
Receptacle box: Terminal block
Tank capacity: 70 l
Consumption at 75 % load: 3. 4 l/h
Autonomy at 75% load: 21 h
Length (mm): 1900
Width (mm): 800
Height (mm): 1230
Dry weight (Kg): 634

Payment methods:

Product: VISA SMARTGENSET K15SG SINGLE-PHASE/ THREE-PHASE GENERATOR 17KVA

Start of Rental

End of Rental

Where to collect / receive the Product

Do you need cables?

SÌNO

Additional Tank?

SÌNO

PERSONAL DATA

Name

Surname

Phone

Company

City

State

Postal Code

Country

VAT or CF

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Ask a question

Product: VISA SMARTGENSET K15SG SINGLE-PHASE/ THREE-PHASE GENERATOR 17KVA

Full Name

Company

Phone

City

Country

Postal code

Message

reCAPTCHA

Offer on letterhead

Product: VISA SMARTGENSET K15SG SINGLE-PHASE/ THREE-PHASE GENERATOR 17KVA

Name

Surname

Company

VAT

Phone

City

Country

Postal code

Shipping address

Message

I authorize the processing of data pursuant to Legislative Decree 196/2003. I declare that I have read the Privacy Policy*

reCAPTCHA

Reference SMARTGENSET K15SG

Data sheet

Phase: Single phase / Three phase
Maximum power single phase (KW): 4.5
Continuous power single phase (KW): 4
Maximum power single phase (KVA): 5.7
Continuous power single phase (KVA): 5
Maximum power three phase (KW): 13
Continuous power three phase (KW): 12
Maximum power three phase (KVA): 17
Continuous power three phase (KVA): 15
Fuel: Diesel
Frequency (Hz): 50
Voltage (V): 230 / 400
Sockets configuration: Terminal box
Engine: Kholer KDW1603
Emissions Regulations: Stationary Use
Engine rpm (rpm): 1500
Speed governor: Mechanical
Starting system: Electric
Cooling: Water
Alternator: STAMFORD S0L1-P1
Poles: 4
Fuel tank capacity (L): 70
Consumption (L/h): 3.4 at 75% load
Running time (h): 21 at 75% of the load
Length (mm): 1900
Width (mm): 800
Height (mm): 1230
Dry weight (Kg): 634
Silenced: Yes
Super silenced: Yes
Product type: Generator
ATS Switch device: Yes
Voltage regulator: AVR
Engine manufacturer: Kholer

Specific References

Condition New

VISA SMARTGENSET K15SG SINGLE-PHASE/ THREE-PHASE GENERATOR 17KVA

The VISA SMARTGENSET K15SG Single Phase / Three Phase Generator is equipped with a Kholer KDW1603 Diesel powered engine and is capable of delivering a maximum power of 17KVA, complete with AVR voltage regulator.

The VISA SMARTGENSET K15SG is compact and easy to use, with sound-absorbing panel enclosures that significantly lower noise emissions and make it supersilenced.

The generator is composed of a STAMFORD S1L2-K1 alternator with AVR voltage regulator that allows its use even with sensitive to current surges.

The AVR is a device that allows you to keep the output more constant and less dependent on the load. Thanks to this board there are fewer drops or spikes in current and this makes it safer to use the various devices connected, improving their performance and durability.

VISA SMARTGENSET K15SG is equipped with electric start and with a low fuel consumption, in fact it consumes only 3.4 liters/hour at 75% of the load for an autonomy of up to 21 hours of operation. VISA SMARTGENSET K15SG is equipped with electric start or Authomatic Transfer Switch ATS, which allows the automatic start in case of blackout.

ATS AUTOMATIC TRANSFER SWITCH

The VISA SMARTGENSET K15SG generator is predisposed for the connection with the ATS Authomatic Transfer Switch. Thanks to which you won't have to worry about black-outs anymore because if there is a power failure this panel is able to start the group automatically and will allow you to continue your activity without losing your work data.

TECHNICAL FEATURES VISA SMARTGENSET K15SG

Phase Type: SinglePhase / ThreePhase
SinglePhase Continuous Power: 5 KVA / 4 KW
SinglePhase Maximum Power: 5.7 KVA / 4. 5 KW
Threephase Continuous Power: 15 KVA / 12 KW
Threephase Maximum Power: 17 KVA / 13 KW
Motor: Kholer KDW1603
Power Supply: Diesel
Motor RPM: 1500 rpm
RPM Adjustment: Mechanical
Alternator: STAMFORD S0L1-P1
Voltage regulator: AVR
Voltage: 230 / 400 V
Frequency: 50 Hz
Receptacle box: Terminal block
Tank capacity: 70 l
Consumption at 75 % load: 3. 4 l/h
Autonomy at 75% load: 21 h
Length (mm): 1900
Width (mm): 800
Height (mm): 1230
Dry weight (Kg): 634

Are you looking for a generator with different technical characteristics? Here you can find the full range of VISA generators and other specialized brands.

Pictures and technical data are not binding
