MOSA GE185 FXC 153KW generating set

MOSA GE185 FXC is a three-phase generator with FPT (IVECO) N67 TM4 diesel engine capable of delivering a maximum power of 153KW. The MOSA GE185 FXC is equipped with an electric starter.

The alternator of the MOSA GE185 FXC is synchronous, three-phase, self-excited, self-regulated, brushless with class H insulation with AVR voltage regulator.

MOSA GE185 FXC is compact and convenient to maneuver and transport thanks to its compact size, with a weight of 2200 kg as well as the practical pierceable base. Generator set with cowling to reduce noise emissions that makes it supersilenced.

The MOSA Generator with 230 liters tank has a fuel consumption of 36.6 litres/hour at 75% of the load for an autonomy of more than 8.4 hours.

MOSA GE185 FXC Technical Specifications:

NOMINAL OUTPUT POWER
Three-phase Stand-by power: 192 kVA (153.6 kW) / 400V / 277A
Three-phase PRP power: 175 kVA (140 kW) / 400V / 252.6A
Three-phase COP power: 140 kVA (112 kW) / 400V / 202A
Frequency: 50 Hz

ENGINE DATA
Model FPT (IVECO) N67 TM4 (Stage 3A)
Net standby output 165 kW (224 hp)
Net PRP output 150 kW (190 hp)
Net COP output 119 kW (162 hp)
Cylinders / Displacement 6/ 6700 cm³ (6. 7 lit.)
Bore / Stroke 104 / 132 (mm)
Compression ratio 17. 5 : 1
BMEP (Effective Average Pressure :
LTP - PRP)
2030 kPa - 1850 kPa
Mechanical RPM Controller
FUEL CONSUMPTION
110 % (Stand-by Power) 42. 2 lit./h
100 % PRP 36.6 lit./h
75 % PRP 29.4 lit./h
50 % PRP 18 lit./h

GENERAL SPECIFICATIONS
Tank capacity: 230 liters
Range of operating time (75% PRP): 8.4 h
Measured acoustic power LwA: 95.3 dB(A) (70. 3 dB(A) @ 7m)
Guaranteed acoustic power LwA: 97 dB(A) (72 dB(A) @ 7m)
Length: 3400 mm
Width: 1200 mm
Height: 1800 mm
Dry weight: 2200 kg

If you are looking for another product like MOSA GE185 FXC generator set then you can browse our catalog for more land based generator sets.

Images and technical data are not binding.
